- More than 2,200 dealer outlets Cat factory-trained dealer technicians service every aspect of your petroleum engine Caterpillar parts and labor warranty Preventive maintenance agreements available for repairbefore-failure options S.O.SSM program matches your oil and coolant samples against Catepillar set standards to determine: - Internal engine component condition - Presence of unwanted.
- Welcome to CatSellerOnline, full service Caterpillar service and repair shop manuals reference resources. We offer original OEM Caterpillar repair shop servi.
- This manual contains safety, operation instructions, lubrication and maintenance information. This manual should be stored in or near the engine area in a literature holder or literature storage area. Read, study and keep it with the literature and engine information. English is the primary language for all Cat publications.
G3304 GAS PETROLEUM ENGINE 71 bkW (95 bhp) LEHW0019-00. Page.3.of.4 Supersedes.LEHW0614-04 G3304 Gas Petroleum Engine — 1800 rpm TM9744-06.
Catalog:
Model:
Complete digital official shop manual contains service, maintenance, and troubleshooting information for the Caterpillar 3208 Engine. Diagnostic and repair procedures are covered in great detail to repair, maintain, rebuild, refurbish or restore your engine like a professional mechanic in local service/repair workshop. This cost-effective quality manual is 100% complete and intact as should be without any missing pages. It is the same factory shop manual used by dealers that guaranteed to be fully functional to save your precious time.
This manual for Caterpillar3208 Engine is divided into different sections. Each section covers a specific component or system and, in addition to the standard service procedures, includes disassembling, inspecting, and assembling instructions. A table of contents is placed at the beginning of each section. Pages are easily found by category, and each page is expandable for great detail. It is in the cross-platform PDF document format so that it works like a charm on all kinds of devices. You do not need to be skilled with a computer to use the manual.
MANAUL LIST:
SENR3581 - Specifications (3208 Marine Engine).pdf
SEBR0541 - Service Manual (3208 Diesel Truck Engine)
SEGV3008 - Systems Operation (Fundamentals Electrical System for All Caterpillar Products)
SENR2131 - Specifications (3208 Marine Engine)
SENR2133 - Specifications (3208 Marine Engine Attachments)
SENR2135 - Disassembly and Assembly (3208 Marine Engine)
SENR3130 - Torque Specifications
SENR3581 - Disassembly and Assembly (3208 Marine Engine)
SENR3581 - Systems Operation (3208 Marine Engine)
SENR3581 - Testing and Adjusting (3208 Marine Engine)
SENR3581 - Troubleshooting (3208 Marine Engine)
SEBU6090 - Engine Safety (3208 Marine Engine).pdf
SEBU6090 - Maintenance Intervals (3208 Marine Engine).pdf
SENR2132 - Systems Operation (3208 Marine Engine).pdf
SENR2132 - Testing & Adjusting (3208 Marine Engine).pdf
SENR2134 - Systems Operation (3208 Marine Engine Attachments).pdf
SENR2134 - Testing & Adjusting (3208 Marine Engine Attachments).pdf
RENR1377 - Systems Operation (Electric Protection System Energize-To-Run for Generator Set, Industrial & Marine Diesel Engines)
RENR1377 - Testing & Adjusting (Electric Protection System Energize-To-Run for Generator Set, Industrial & Marine Diesel Engines)
SENR3981 - Schematic - Fluid Power & Electrical Graphic Symbols
UENR3262 - Disassembly & Assembly - Seal Installation
SEBF9050 - Applied Failure Analysis - Engine Valve Failure Modes{1100, 1105}.pdf
SEBU6875 - Owner's Manual (Caterpillar Driver Information Display).pdf
SENR2995 - Product Safety.pdf
SENR3130 - Specifications (Torque Specifications for All Caterpillar Products).pdf
Spec+Sheets Cat+3208+Propulsion.pdf
Spec+Sheets+-+Cat+3208+Propulsion.pdf
…
ENGINE - GENERATOR SET
Model Prefix
3208 GEN SET ENGINE 29A
3208 GEN SET ENGINE 2HG
3208 GEN SET ENGINE 30A
3208 GEN SET ENGINE 5YF
ENGINE - INDUSTRIAL
Model Prefix
3208 INDUSTRIAL ENGINE 03Z
3208 INDUSTRIAL ENGINE 90N
3208 REMAN ENGINE 9WC
ENGINE - MACHINE
Model Prefix
3208 ENGINE - MACHINE 03Z
3208 ENGINE - MACHINE 79V
3208 ENGINE - MACHINE 90N
3208 ENGINE - MACHINE 93Z
ENGINE - TRUCK
Model Prefix
3208 REMAN ENGINE 5CD
3208 REMAN ENGINE 62W
3208 TRUCK ENGINE 02Z
3208 TRUCK ENGINE 32Y
3208 TRUCK ENGINE 40S
3208 TRUCK ENGINE 51Z
MARINE PRODUCTS
Model Prefix
3208 MARINE ENGINE 01Z
3208 MARINE ENGINE 75V
EXCERPT:
Caterpillar G3304 Service Manual Transmission
Fuel Injection Pump Housing And Governor
SMCS - 1286-11; 1286-12
Remove Fuel Injection Pump Housing And Governor
Caterpillar G3304 Service Manual Download
View Image
start by:
a) remove air cleaner
b) remove fuel injection lines
c) Remove air inlet manifold
View Image
1. Remove plug from cover in fuel injection pump housing and install tool (A). Turn the crankshaft (clockwise) until the timing pin drops into the groove (slot) in the fuel injection pump camshaft.
View Image
2. Remove two nuts (2) and the tachometer drive housing (1).
3. Remove tachometer drive shaft (3).
View Image
4. Install tooling (B) into the camshaft drive gear for the fuel injection pump. Turn bolts (4) evenly until the drive gear is free of the shaft. Remove tooling (B).
View Image
5. Remove the plug from the timing hole in the front cover and install a 5/16'-18 NC bolt (5) 2 1/2 in. long. The cover bolt from hole (6) can be used. Turn the crankshaft (clockwise) until bolt can be installed into the timing gear and is in the center of the timing hole. The camshaft for the fuel injection pump is now in correct time to the engine.
View Image
6. Remove line (7). Remove bolts (8) from base of the fuel injection pump housing.
View Image
7. Remove the fuel injection pump housing and governor as a unit.
Install Fuel Injection Pump Housing And Governor
1. Put the fuel injection pump housing and governor in position on the engine. Install the bolts and lines.
2. Install the tachometer drive shaft and tighten it to a torque of 110 ± 10 lb. ft. (149 ± 14 N·m).
3. To check the timing, remove the timing pin and the bolt. Turn the crankshaft (clockwise) two revolutions and install the timing pin and bolt back in place. If the timing pin or bolt can not be installed, the fuel injection pump camshaft must be put into time again before Step 4 is done.
Caterpillar G3304 Service Manuals
4. Remove the bolt from the timing gear. Install the plug into the timing hole.
5. Remove the timing pin from the timing groove (slot) in the fuel injection pump camshaft.
6. Install the tachometer drive housing.
end by:
a) install air inlet manifold
b) install fuel injection lines
Manual Car Service Manuals
c) install air cleaner
...
